Batten Mount PIR occupancy switch can be mounted onto the end of lighting battens via the 20mm knock out. The switch includes the connection 20mm thread and 1 metre of wire tails to connect to the lighting ballast.

Ideal for use in factories, warehouses, offices, schools, hospitals etc. Stylish, cost effective and easy to fit. IP53 rated enclosure. Real time photocell status indicator. Easy to adjust photocell override facility.

Weatherproof: IP53 rating Detection range: Up to 5m, for optimum coverage recommended mounting height between 2.4 and 5m Detection angle: 100° Time lag: 10 seconds to 40 minutes (adjustable) Photocell range: 100 lux to 3000 lux (adjustable) Loading: Up to 10 amps (2500W) resistive loads and tungsten. Up to 6 amps (1500W) fluorescent (switch start). Up to 3 amps (750W) electronic or wire wound transformers, compact fluorescent or LED lamps. Dimensions: 120 x 50 x 36mm plus 1 metre wire tails
